Extension Points
YouTrack offers a collection of extension points where an app developer can embed a widget in the UI. These widgets support specific interactions that are not available to users unless they install and activate the app. On this page, you can find information about these extension points.
Here is the overview of all possible extension points with their scopes. To learn about widget scopes, see Scope.
Extension Point | Scope | Description |
---|---|---|
ADMINISTRATION_MENU_ITEM | Global | A page that has its own item in the administration menu. |
ARTICLE_ABOVE_ACTIVITY_STREAM | Article | The area in an article above the activity stream. |
ARTICLE_BELOW_SUMMARY | Article | The area in an article below the title. |
ARTICLE_OPTIONS_MENU_ITEM | Article | An item in the article toolbar that invokes the widget. |
DASHBOARD_WIDGET | Global | The dashboard. |
HELPDESK_CHANNEL | Project | An extra channel for tickets. This extension point is only available for helpdesk projects. |
ISSUE_ABOVE_ACTIVITY_STREAM | Issue | The area in an issue above the activity stream. |
ISSUE_BELOW_SUMMARY | Issue | The area in an issue below the issue summary. |
ISSUE_FIELD_PANEL_FIRST | Issue | The area in an issue above the custom field panel. |
ISSUE_FIELD_PANEL_LAST | Issue | The area in an issue below the custom field panel. |
ISSUE_OPTIONS_MENU_ITEM | Issue | An item in the issue toolbar that invokes the widget. |
MAIN_MENU_ITEM | Global | A separate application page with a menu item in the header. |
MARKDOWN | Global | The area in a Markdown-formatted text. |
PROJECT_SETTINGS | Project | A separate tab in the project settings. |
USER_CARD | User | The area in the user card that you see when you hover over the username in an issue or article. |
USER_PROFILE_SETTINGS | User | A separate tab in the user profile. |
Register a Widget with the Host API
If you want your widget to send HTTP requests to YouTrack or communicate with it using any of the YouTrack APIs, add a script that registers the widget in YouTrack in the HTML code of the widget.
You need to register your app in YouTrack, for example, when sending alerts to YouTrack from the widget. Once you've registered the app, you can use the Host API to send alerts in YouTrack or invoke functions implemented as custom HTTP handlers.
Here you can see an example of the registration script:
For more details about the Host API, see Host API.
Administration Menu Item
Name | Description | Scope |
---|---|---|
ADMINISTRATION_MENU_ITEM | This extension point lets you create a page that has its own item in the administration menu. | Global |
![A menu item for a widget that adds an administration page. A menu item for a widget that adds an administration page.](https://resources.jetbrains.com/help/img/youtrack/apps-places-administration-page-menu-item.png)
![An example of a widget that adds a page to the administration section of YouTrack. An example of a widget that adds a page to the administration section of YouTrack.](https://resources.jetbrains.com/help/img/youtrack/apps-places-administration-page.png)
Article above Activity Stream
Name | Description | Scope |
---|---|---|
ARTICLE_ABOVE_ACTIVITY_STREAM | This extension point lets you add a custom widget to the area in an article above the activity stream. | Article |
![An example of a widget that appears above the activity stream in an article. An example of a widget that appears above the activity stream in an article.](https://resources.jetbrains.com/help/img/youtrack/apps-places-article-above-activity.png)
Article Below Title
Name | Description | Scope |
---|---|---|
ARTICLE_BELOW_SUMMARY | This extension point lets you add a custom widget to the area in an article below the title. | Article |
![An example of a widget that appears below the article title. An example of a widget that appears below the article title.](https://resources.jetbrains.com/help/img/youtrack/apps-places-article-below-summary.png)
Article Options Menu Item
Name | Description | Scope |
---|---|---|
ARTICLE_OPTIONS_MENU_ITEM | This extension point lets you add an item to the option menu in an article. When a user selects this option, the custom widget is displayed. | Article |
![An example of an app that adds a custom item to the option menu in an article. An example of an app that adds a custom item to the option menu in an article.](https://resources.jetbrains.com/help/img/youtrack/apps-places-article-toolbar-item.png)
Dashboard Widget
Name | Description | Scope |
---|---|---|
DASHBOARD_WIDGET | A widget that can be displayed on a dashboard. Apps that use this extension point generate a special embedding component each time its widgets are displayed on a dashboard. This component is supported by a more extensive | Global |
![An example of a widget that can be displayed on a dashboard. An example of a widget that can be displayed on a dashboard.](https://resources.jetbrains.com/help/img/youtrack/apps-places-dashboard-widget.png)
Helpdesk Channel
Name | Description | Scope |
---|---|---|
HELPDESK_CHANNEL | This extension point lets you create an extra channel for creating helpdesk tickets. It is only available for helpdesk projects. | Project |
![An example of a widget that creates a custom helpdesk channel. An example of a widget that creates a custom helpdesk channel.](https://resources.jetbrains.com/help/img/youtrack/apps-places-ticket-channel-page.png)
Issue above Activity Stream
Name | Description | Scope |
---|---|---|
ISSUE_ABOVE_ACTIVITY_STREAM | This extension point lets you add a custom widget to the area in an issue above the activity stream. | Issue |
![An example of a custom widget in an issue above the activity stream. An example of a custom widget in an issue above the activity stream.](https://resources.jetbrains.com/help/img/youtrack/apps-places-issue-above-activity.png)
Issue below Summary
Name | Description | Scope |
---|---|---|
ISSUE_BELOW_SUMMARY | This extension point lets you add a custom widget to the area in an issue below the issue summary. | Issue |
![An example of a custom widget in an issue below the summary. An example of a custom widget in an issue below the summary.](https://resources.jetbrains.com/help/img/youtrack/apps-places-issue-main-area.png)
Issue Field Panel First
Name | Description | Scope |
---|---|---|
ISSUE_FIELD_PANEL_FIRST | This extension point lets you add a custom widget to the area in an issue above the custom field panel. | Issue |
![An example of a custom widget shown in the area above the custom field panel. An example of a custom widget shown in the area above the custom field panel.](https://resources.jetbrains.com/help/img/youtrack/apps-places-issue-sidebar-top.png)
Issue Field Panel Last
Name | Description | Scope |
---|---|---|
ISSUE_FIELD_PANEL_LAST | This extension point lets you add a custom widget to the area in an issue below the custom field panel. | Issue |
![An example of a custom widget shown in the area below the custom field panel. An example of a custom widget shown in the area below the custom field panel.](https://resources.jetbrains.com/help/img/youtrack/apps-places-issue-sidebar.png)
Issue Options Menu Item
Name | Description | Scope |
---|---|---|
ISSUE_OPTIONS_MENU_ITEM | This extension point lets you add an item to the option menu in an issue. When a user selects this option, the custom widget is displayed. | Issue |
![An example of an app that adds a custom action to the option menu in an issue. An example of an app that adds a custom action to the option menu in an issue.](https://resources.jetbrains.com/help/img/youtrack/apps-places-issue-toolbar-item.png)
Main Menu Item
Name | Description | Scope |
---|---|---|
MAIN_MENU_ITEM | This extension point lets you add a dedicated page to YouTrack that is accessible from the main menu. | Global |
![The header menu item for an app that uses this extension point. The header menu item for an app that uses this extension point.](https://resources.jetbrains.com/help/img/youtrack/apps-places-page-header-menu-item.png)
![An example of a custom widget that is accessible from the main menu. An example of a custom widget that is accessible from the main menu.](https://resources.jetbrains.com/help/img/youtrack/apps-places-page.png)
Markdown
Name | Description | Scope |
---|---|---|
MARKDOWN | A custom widget that can be used to embed content in areas that support rich text. These widgets can be embedded in issue descriptions, knowledge base articles, and comments in issues, tickets, and articles. Despite the name of this extension point, this widget can embed content when editing in Visual mode as well as Markdown. Apps that use this extension point generate a special embedding component each time its widgets are inserted into a text field. This component is supported by a more extensive | Global |
![An example of a custom widget that displays embedded content. An example of a custom widget that displays embedded content.](https://resources.jetbrains.com/help/img/youtrack/apps-places-markdown.png)
Project Settings
Name | Description | Scope |
---|---|---|
PROJECT_SETTINGS | This extension point lets you create a separate tab in the project settings. | Project |
![An example of a widget that adds a dedicated tab to the project settings. An example of a widget that adds a dedicated tab to the project settings.](https://resources.jetbrains.com/help/img/youtrack/apps-places-project-administration-area.png)
User Card
Name | Description | Scope |
---|---|---|
USER_CARD | This extension point lets you customize the area in the user card that you see when you hover over a username in an issue, ticket, or article. | User |
![An example of widget that displays information on user cards. An example of widget that displays information on user cards.](https://resources.jetbrains.com/help/img/youtrack/apps-places-user-card.png)
User Profile Settings
Name | Description | Scope |
---|---|---|
USER_PROFILE_SETTINGS | This extension point lets you create a separate tab in the user profile. | User |
![An example of a widget that adds a dedicated tab to the user profile. An example of a widget that adds a dedicated tab to the user profile.](https://resources.jetbrains.com/help/img/youtrack/apps-places-user-profile-area.png)
